TECHNICAL SHEET MAN Tractor unit MAN TGS 18.320/360 4x2 BLS EURO 6
Main characteristics
| Range | TGS |
| Model | 18.320/360 4x2 BLS EURO 6 |
| Type of vehicle | Tractor |
| Axles configuration | 4x2 |
| Empty weight | - |
| GVWR | 19 000 kg |
| Maximum allowable weight | 44 000 kg |
| Max. front weight | 7500 kg |
| Max. back weight | 13 000 kg |
Measurements
| M (Short) | L (Average) | LX (Long) | ||||
|---|---|---|---|---|---|---|
| Model | 36 | 39 | 36 | 39 | 36 | 39 |
| A / Overall length | 5,875 m | 6,175 m | 5,875 m | 6,175 m | 5,875 m | 6,175 m |
| B / Width | 2,240 m | |||||
| C / Chassis cab width | - | |||||
| D / Chassis cab width rear under-frame | - | |||||
| E / Front overhang | 1,475 m | |||||
| F / Wheel base | 3,600 m | 3,900 m | 3,600 m | 3,900 m | 3,600 m | 3,900 m |
| H1 / Empthy chassis height (front) | - | |||||
| H1 / Loaded chassis height (front) | - | |||||
| N / Rear overhang | 0,800 m | |||||
| T / Empty cab height | 3,108 m | |||||
| Y / Max. fifth wheel lead | 0,776 m | 0,840 m | 0,736 m | 0,797 m | 0,736 m | 0,797 m |
| Y / Minimum fifth wheel lead | 0,327 m | 0,353 m | 0,282 m | 0,304 m | 0,282 m | 0,304 m |
| Y / Standard fifth wheel lead | 0,585 m | |||||
| Turning radius inbetween walls | 6,600 m | 7,050 m | 6,600 m | 7,050 m | 6,600 m | 7,050 m |
Masses
| M (Short) | L (Average) | LX (Long) | ||||
|---|---|---|---|---|---|---|
| Model | 36 | 39 | 36 | 39 | 36 | 39 |
| Total weight | 6 855 kg | 6 870 kg | 7 020 kg | 7 035 kg | 7 300 kg | 7 315 kg |
| Minimum weight on front axle | 4 200 kg | |||||
| Minimum weight on rear axle | 1 850 kg | |||||
| Chassis cab front axle weight | 4 775 kg | 4 780 kg | 4 940 kg | 4 945 kg | 5 220 kg | 5 225 kg |
| Chassis cab rear axle weight | 2 080 kg | 2 090 kg | 2 080 kg | 2 090 kg | 2 080 kg | 2 090 kg |
Engines
| Name | MAN D2066LF80 | MAN D2066LF81 |
| Administrative power | 28 cv | 28 cv |
| Bore × stroke | 120 x 155 mm | 120 x 155 mm |
| Catalyst and injection | SCR et injection AdBlue® | SCR et injection AdBlue® |
| Engine size | 10.518 l | 10.518 l |
| Max. power | 264 kW (360 ch) à 1900 tr/min | 235 kW (320 ch) 1900 tr/min |
| Maximum torque | 1800 Nm entre 1000 et 1400 tr/min | 1600 Nm entre 1000 et 1400 tr/min |
| Name | MAN D2066LF80 | MAN D2676LF52 |
