TECHNICAL SHEET MAN Tractor unit MAN TGX 18.360 - 4x2- BLS - (SC)
Main characteristics
| Range | TGX |
| Model | 18.360 - 4x2- BLS - (SC) |
| Type of vehicle | Tractor |
| Axles configuration | 4x2 |
| Empty weight | - |
| GVWR | 19 000 kg |
| Maximum allowable weight | 44 000 kg |
| Max. front weight | 8 000 kg |
| Max. back weight | 13 000 kg |
Measurements
| XL | XLX | XXL (surélevée) | ||||
|---|---|---|---|---|---|---|
| Model | 36 | 39 | 36 | 39 | 36 | 39 |
| A / Overall length | 5,842 m | 6,142 m | 5,842 m | 6,142 m | 5,842 m | 6,142 m |
| B / Width | 2,240 m | |||||
| C / Chassis cab width | - | |||||
| D / Chassis cab width rear under-frame | - | |||||
| E / Front overhang | 1,492 m | |||||
| F / Wheel base | 3,600 m | 3,900 m | 3,600 m | 3,900 m | 3,600 m | 3,900 m |
| H1 / Empthy chassis height (front) | - | |||||
| H1 / Loaded chassis height (front) | - | |||||
| N / Rear overhang | 0,750 m | |||||
| T / Empty cab height | 3,403 m | |||||
| Y / Max. fifth wheel lead | 0,826 m | 0,895 m | 0,664 m | 0,719 m | 0,658 m | |
| Y / Minimum fifth wheel lead | 0,199 m | 0,214 m | 0,193 m | 0,209 m | 0,186 m | 0,200 m |
| Y / Standard fifth wheel lead | 0,585 m | |||||
| Turning radius inbetween walls | 6,450 m | 6,900 m | 6,450 m | 6,900 m | 6,450 m | 6,900 m |
Masses
| XL | XLX | XXL (surélevée) | ||||
|---|---|---|---|---|---|---|
| Model | 36 | 39 | 36 | 39 | 36 | 39 |
| Total weight | 7 520 kg | 7 535 kg | 7 540 kg | 7 555 kg | 7 565 kg | 7 580 kg |
| Minimum weight on front axle | 1 700 kg | |||||
| Minimum weight on rear axle | 4 100 kg | |||||
| Chassis cab front axle weight | 5 365 kg | 5 370 kg | 5 385 kg | 5 390 kg | 5 410 kg | 5 415 kg |
| Chassis cab rear axle weight | 2 155 kg | 2 165 kg | 2 155 kg | 2 165 kg | 2 155 kg | 2 165 kg |
Engines
| Name | MAN D2066LF85 |
| Administrative power | 28 cv |
| Bore × stroke | 120 x 155 mm |
| Catalyst and injection | SCR et injection AdBlue® |
| Coolant (without retarder) | - |
| Cooling circuit (with retarder) | - |
| Engine size | 10.518 l |
| Max. power | 265 kW/360 ch à 1800 tr/min |
| Maximum torque | 1800 Nm entre 930 et 1400 tr/min |
| Motor retarder - braking power | - |
| Name | MAN D2066LF85 |
| Oil capacity | - |
