TECHNICAL SHEET MAN Tractor unit MAN TGX 18.540-640 4x2 LLS EURO 6c
Main characteristics
| Range | TGX |
| Model | 18.540-640 4x2 LLS EURO 6c |
| Type of vehicle | Tractor |
| Axles configuration | 4x2 |
| Empty weight | - |
| GVWR | 19 000 kg |
| Maximum allowable weight | 44 000 kg |
| Max. front weight | 7 500 kg |
| Max. back weight | 13 000 kg |
Measurements
| XL | XLX | XXL | ||||
|---|---|---|---|---|---|---|
| Model | 36 | 39 | 36 | 39 | 36 | 39 |
| A / Overall length | 5,875 m | 6,175 m | 5,875 m | 6,175 m | 5,875 m | 6,175 m |
| B / Width | 2,500 m | |||||
| C / Chassis cab width | - | |||||
| D / Chassis cab width rear under-frame | - | |||||
| E / Front overhang | 1,475 m | |||||
| F / Wheel base | 3,600 m | 3,900 m | 3,600 m | 3,900 m | 3,600 m | 3,900 m |
| H1 / Empthy chassis height (front) | - | |||||
| H1 / Loaded chassis height (front) | - | |||||
| N / Rear overhang | 0,800 m | |||||
| T / Empty cab height | 3,264 m | |||||
| Y / Max. fifth wheel lead | 0,610 m | 0,632 m | 0,579 m | 0,626 m | 0,572 m | 0,619 m |
| Y / Minimum fifth wheel lead | 0,142 m | 0,121 m | 0,107 m | 0,114 m | 0,099 m | 0,106 m |
| Y / Standard fifth wheel lead | 0,585 m | |||||
| Turning radius inbetween walls | 6,500 m | 6,900 m | 6,450 m | 6,900 m | 6 450 m | 6 900 m |
Masses
| XL | XLX | XXL | ||||
|---|---|---|---|---|---|---|
| Model | 36 | 39 | 36 | 39 | 36 | 39 |
| Total weight | 7 465 kg | 7 555 kg | 7 560 kg | 7 575 kg | 7 585 kg | 7 600 kg |
| Minimum weight on front axle | 4 100 kg | |||||
| Minimum weight on rear axle | 1 700 kg | |||||
| Chassis cab front axle weight | 5 545 kg | 5 645 kg | 5 660 kg | 5 665 kg | 5 685 kg | 5,690 kg |
| Chassis cab rear axle weight | 1 920 kg | 1 910 kg | 1 900 kg | 1 910 kg | 1 900 kg | 1 910 kg |
Engines
| Name | MAN D3876LF07 | MAN D3876LF08 | MAN D3876LF09 |
| Administrative power | - | 41 cv | - |
| Bore × stroke | - | 138 x 170 mm | - |
| Catalyst and injection | Catalyseur SCR et injection AdBlue® | Catalyseur SCR et injection AdBlue® | Catalyseur SCR et injection AdBlue® |
| Coolant (without retarder) | - | - | - |
| Cooling circuit (with retarder) | - | - | - |
| Engine size | - | 15,2 L | - |
| Max. power | 427 kW (580 ch) à 1800 tr/min | 397 kW (540 ch) à 1800 tr/min | 471 kW (640 ch) à 1800 tr/min |
| Maximum torque | 2900 Nm de 900 à 1380 tr/min | 2700 Nm de 900 et 1380 tr/min | 3000 Nm de 900 à 1380 tr/min |
| Motor retarder - braking power | - | - | - |
| Name | MAN D3876LF07 | MAN D3876LF08 | MAN D3876LF09 |
| Oil capacity | - | - | - |
